    EF25 10 Pins High Frequency Transformer Customized With Fast Lead Time

    Ask Lasest Price
    Brand Name : TIGER
    Model Number : TG-EF25
    Certification : ISO, CE,UL, RoHS
    Price : negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 10000 PCS/Day
    Delivery Time : 15-20 Working days
    • Product Details
    • Company Profile

    EF25 10 Pins High Frequency Transformer Customized With Fast Lead Time

    EF25 10 pins Customized High Frequency Transformer with fast lead time



    Winding structure


    No.

    Margin

    Tape

    StartFinishWire sizeTurnsWinding wayTapeNote
    N1792UEW φ0.23*240 TSClose winding2 TS
    N22+2542UEW φ0.23*236 TSClose winding2 TS
    N32+2982UEW φ0.23*234 TSClose winding2 TS
    N42+21102UEW φ0.2012 TSSparse winding2 TS
    N52+2232UEW φ0.206 TSSparse winding2 TS

    NOTES:


    1,Core fix tape 2 TS

    2,Winding level off, do not cross, overlapping.

    3,The finished product Varnish immersion


    Electrical Datasheet

    ItemTest PointRangeTest ConditionTest machine
    InductanceL(Pin7-8)710mH ±5%10KHz/0.1VCH-1062A
    HI-POTPRI - SEC2000VAC5mA 3SECYD9850A
    Winding - Core2000VAC
    Leakage

    LK(Pin7-8)

    Shorted 4-5

    12uH Max10 KHz/0.1VCH-1062A


    • Core mounted Horizontal or Vertical
    • Hipot voltage:2500Vrms
    • Ferrite core material
    High-temperature resistant
    High efficiency of over 95%
    Working frequency range 20kHZ-500kHZ
    High isolation strength
    Lower profile and weight
    High power density
    Operating temperature -40℃to+125℃
    • Custom designs available


    Application:

    TIGER designs and manufactures a wide range of products for critical applications in various industries, including but not limited to:
    · Automotive
    · Consumer Electronics
    · Industrial
    · Medical
    · Military & Aerospace
    · Telecommunications
    We are uniquely positioned to offer the highest quality products for critical applications as well as cost effective products for price sensitive applications.
    Packing:
    FAQ
    1. Q: Can I get some samples?
    A: Yes, sample order is available for quality check and market test.
    2. Q: What's the delivery time?
    A: Sample order needs 7 days. Formal order needs 15-20 days.
    3. Q: What's your payment terms?
    A: We usually accept T/T at sight as the main payment terms, and other payment can also be negotiated.
    4. Q: Do you have the prodcts in stock?
    A: Yes,we will keep some general ones in stock.
    5. Q: Can I mix different models in one container?
    A: Yes,different models can be mixed up.
    6. Q: Do you customize for customer or accept OEM Orders ?
    A: Yes,we provide designing and customizing services. OEM orders are also accepted.
