High Withstanding Voltage R Shape R8*30 Magnetic Bar Unshielded Power Inductor
Features:
• Use ferrite core,high frequency.
• Low DC resistance, High saturation current.
• Lead free product,RoHs Compliant
• Widely used in switching power supply,power amplifier,output antenna ,filter,Displayer,UPS and etc.
• Available in 367 standard values covering a wide range of inductance and current
• High saturation flux density material is ideal for use in switching regulated power supply applications
• Ideal wherever high current choke values in a small physical size are needed
• Operating Temperature:-40℃∽+125℃
Specifaction :
Part No. | A | B | C | D |
Max | ±1 | ±0.5 | ±0.15 | |
RAR0830-4R7M | 12.2 | 22.5 | 9.85 | 1.8 |
RAR0830-5R6M | 11.8 | 22 | 9.65 | 1.6 |
RAR0830-6R8M | 11.6 | 21 | 9.45 | 1.4 |
RAR0830-8R2M | 11.2 | 21 | 9.35 | 1.3 |
RAR0830-100M | 10.9 | 22 | 9.25 | 1.2 |
RAR0830-150M | 10.6 | 23 | 9.05 | 1 |
RAR0830-220M | 10.2 | 22.5 | 8.85 | 0.8 |
Application:
TIGER designs and manufactures a wide range of products for critical applications in various industries, including but not limited to:
• Automotive
• Consumer Electronics
• Industrial
• Medical
• Military & Aerospace
• Telecommunications
We are uniquely positioned to offer the highest quality products for critical applications as well as cost effective products for price sensitive applications.
![]() |
